HTD8M Timing Belt
HTD8M PU timing belt is a type of synchronous belt that features an HTD (High Torque Drive) profile with an 8 mm pitch and is made from polyurethane with steel or Kevlar cord.
- Excellent Torque Transmission
- High Wear Resistance
- Reliable Synchronous Operation
- Low Maintenance Requirements
HTD8M Timing Belt Description
| Model | HTD8M |
| Material | Polyurethane |
| Pitch | 8mm |
| Color | White/Black |
| Core | Steel/Kevlar |
| Hardness | 90-92 Shore A |
| Length/Width Tolerance | ±0.5mm |
| Thickness Tolerance | ±0.3mm |
| Minimum Pulley Diameter | 44.47mm |
Get Free Quote of HTD8M PU Timing Belt
Engineered for high-performance industrial applications, our HTD8M PU timing belts deliver exceptional strength, durability and precision.
